Overview - ASP.NET Core Form Demo

$(() => { const form = $('#form').dxForm({ labelMode: 'floating', formData: companies[0], readOnly: false, showColonAfterLabel: true, labelLocation: 'left', minColWidth: 300, colCount: 2, }).dxForm('instance'); const companySelectorSelectBox = $('#select-company').dxSelectBox({ displayExpr: 'Name', dataSource: companies, inputAttr: { 'aria-label': 'Company' }, labelMode: 'floating', label: 'Select company', value: companies[0], onValueChanged(data) { form.option('formData', data.value); }, }).dxSelectBox('instance'); const companySelectorText = $('#select-company-text'); $('#label-mode').dxSelectBox({ items: ['outside', 'static', 'floating', 'hidden'], value: 'floating', inputAttr: { 'aria-label': 'Label Mode' }, onValueChanged(data) { form.option('labelMode', data.value); if (data.value === 'outside') { companySelectorSelectBox.option('labelMode', 'hidden'); companySelectorText.show(); } else { companySelectorSelectBox.option('labelMode', data.value); companySelectorText.hide(); } }, }); $('#label-location').dxSelectBox({ items: ['left', 'top'], value: 'left', inputAttr: { 'aria-label': 'Label Location' }, onValueChanged(data) { form.option('labelLocation', data.value); }, }); $('#columns-count').dxSelectBox({ items: ['auto', 1, 2, 3], inputAttr: { 'aria-label': 'Column Count' }, value: 2, onValueChanged(data) { form.option('colCount', data.value); }, }); $('#min-column-width').dxSelectBox({ items: [150, 200, 300], inputAttr: { 'aria-label': 'Min Column Width' }, value: 300, onValueChanged(data) { form.option('minColWidth', data.value); }, }); $('#width').dxNumberBox({ value: undefined, max: 550, inputAttr: { 'aria-label': 'Width' }, onValueChanged(data) { form.option('width', data.value); }, }); $('#read-only').dxCheckBox({ text: 'readOnly', value: false, onValueChanged(data) { form.option('readOnly', data.value); }, }); $('#show-colon').dxCheckBox({ text: 'showColonAfterLabel', value: true, onValueChanged(data) { form.option('showColonAfterLabel', data.value); }, }); });

<!DOCTYPE html> <html xmlns="http://www.w3.org/1999/xhtml" lang="en"> <head> <title>DevExtreme Demo</title> <meta http-equiv="X-UA-Compatible" content="IE=edge" /> <meta http-equiv="Content-Type" content="text/html; charset=utf-8" /> <meta name="viewport" content="width=device-width, initial-scale=1.0, maximum-scale=5.0" /> <script src="https://ajax.googleapis.com/ajax/libs/jquery/3.5.1/jquery.min.js"></script> <script>window.jQuery || document.write(decodeURIComponent('%3Cscript src="js/jquery.min.js"%3E%3C/script%3E'))</script> <link rel="stylesheet" type="text/css" href="https://cdn3.devexpress.com/jslib/25.2.4/css/dx.light.css" /> <script src="js/dx.all.js?v=25.2.4"></script> <script src="data.js"></script> <link rel="stylesheet" type="text/css" href="styles.css" /> <script src="index.js"></script> </head> <body class="dx-viewport"> <div class="demo-container"> <div id="form-demo"> <div class="widget-container"> <div id="select-company-text">Select company:</div> <div id="select-company"></div> <div id="form"></div> </div> <div class="options"> <div class="caption">Options</div> <div class="option"> <span>Label mode:</span> <div id="label-mode"></div> </div> <div class="option"> <span>Label location:</span> <div id="label-location"></div> </div> <div class="option"> <span>Columns count:</span> <div id="columns-count"></div> </div> <div class="option"> <span>Min column width:</span> <div id="min-column-width"></div> </div> <div class="option"> <span>Form width:</span> <div id="width"></div> </div> <div class="option"> <div id="read-only"></div> </div> <div class="option"> <div id="show-colon"></div> </div> </div> </div> </div> </body> </html>

.widget-container { margin-right: 320px; padding: 20px; max-width: 550px; min-width: 300px; } #form { margin-top: 25px; } #select-company-text { display: none; } .options { padding: 20px; position: absolute; bottom: 0; right: 0; width: 260px; top: 0; background-color: rgba(191, 191, 191, 0.15); } .caption { font-size: 18px; font-weight: 500; } .option { margin-top: 10px; }

const companies = [{ ID: 1, Name: 'Super Mart of the West', Address: '702 SW 8th Street', City: 'Bentonville', State: 'Arkansas', ZipCode: 72716, Phone: '(800) 555-2797', Fax: '(800) 555-2171', Website: '', Active: true, }, { ID: 2, Name: 'Electronics Depot', Address: '2455 Paces Ferry Road NW', City: 'Atlanta', State: 'Georgia', ZipCode: 30339, Phone: '(800) 595-3232', Fax: '(800) 595-3231', Website: '', Active: true, }, { ID: 3, Name: 'K&S Music', Address: '1000 Nicllet Mall', City: 'Minneapolis', State: 'Minnesota', ZipCode: 55403, Phone: '(612) 304-6073', Fax: '(612) 304-6074', Website: '', Active: true, }, { ID: 4, Name: "Tom's Club", Address: '999 Lake Drive', City: 'Issaquah', State: 'Washington', ZipCode: 98027, Phone: '(800) 955-2292', Fax: '(800) 955-2293', Website: '', Active: true, }];

Form - Overview
